Felicity 200Ah 12V 2.56kWh Lithium Iron Phosphate (LiFePO₄) Solar Battery FLA12200; Floor-Mounted, Built-in BMS, Over 6,000 Cycles @25°C, 80% DoD, 5-Year Warranty

Felicity 200Ah 12V 2.56kWh Lithium Iron Phosphate (LiFePO₄) Solar Battery FLA12200

Electrical Specifications

• Nominal Voltage: 12.8V
• Nominal Capacity: 200Ah
• Energy Storage Capacity: 2.56kWh
• Voltage Range: 10.8V – 14.6V
• Max Charging Voltage: 14.6V
• Recommended Charging Voltage: 14.2V – 14.6V
• Standard Charging Current: 40A
• Maximum Charging Current: 100A
• Standard Discharge Current: 100A
• Maximum Continuous Discharge Current: 150A
• Charge Cut-off Voltage: 14.6V
• Discharge Cut-off Voltage: 10.8V
• Cycle Life: ≥6,000 cycles @ 25°C, 80% Depth of Discharge (DoD)

Features & Protections

• Cell Type: LiFePO₄ (Lithium Iron Phosphate)
• Built-in Battery Management System (BMS)

Protection Functions:

• Overcharge Protection
• Over-discharge Protection
• Over-current Protection
• Short Circuit Protection
• Temperature Protection
• Balance Function

Design & Installation

• Mounting Type: Floor-Mounted
• Dimensions (L×W×H): 522 × 238 × 218 mm
• Net Weight: Approx. 22.8 kg
• Terminal Type: M8
• Casing Material: Metal

Environmental Conditions

• Operating Temperature Range:

  • Charge: 0°C to +55°C
  • Discharge: –20°C to +60°C
• Storage Temperature: –10°C to +50°C
• Humidity Range: 5% – 95% RH (non-condensing)

Warranty & Certifications

• Warranty: 5 Years
• Certifications: CE, UN38.3, MSDS (varies by batch
